The MR IP68 is a range of compact single pole rocker switches rated up to 16(8) 250V AC. Certified according to UL and ENEC standards, a variety of colours, configurations, terminations and illumination types are available. Panel side sealed to IP68 these rocker switches are ideal for small electrical appliances.
- Compact switch rated up to 16(8) 250V AC
- Panel cut-out 13 x 19 mm or round 20 mm options
- Choice of actuator colours & illumination types
- Available with Quick Connect, solder or PCB terminals
- ENEC and UL certified
Typical applications include instrumentation and small household appliances.
The table below lists a small selection of the available standard options. If you cannot find what you are looking for please contact us.
- Standard Parts
|
Part Number
|
Cut-Out
|
Electrical Rating
|
Configuration
|
Terminal Type
|
Illumination
|
Legend
|
Datasheet
|
|---|---|---|---|---|---|---|---|
| MR2-120C2N-NBBP | 13 x 19 mm | 10(4)A 125/250VAC | S.P.D.T. on-on | Q.C. 4.8 x 0.8 mm | Illuminated 200 - 250VAC | No Legend | |
| MR2-110R2N-NBBQ | 20 mm diameter | 16(8)A 125/250VAC | S.P.S.T. on-off | Q.C. 4.8 x 0.8 mm | No illumination | No Legend | |
| MR2-110R2N-GBRQ | 20 mm diameter | 16(8)A 125/250VAC | S.P.S.T. on-off | Q.C. 4.8 x 0.8 mm | No illumination | No Legend |
Specifications subject to change without notice.
