C2-379R LED Arrow Marking Red Safety Lamp

The C2-379R is a circular heavy-duty red safety lamp with an aluminium housing and a polymethyl methacrylate lens. It features high-performance LEDs emitting 820lm of bright red light in the shape of an arrow designed to project illumination around vehicles to prevent either pedestrian or vehicle collision. Operating at 9 - 96VDC, it consumes approximately 10W of power. Its rugged design with an IP67 ingress protection rating means it is well suited to taxing environments. The lamp operates in temperatures ranging from -30°C to +65°C and complies with EN50498. Ideal for material handling, it includes a single-bolt mount for easy installation at any number of points on a vehicle. Also Available as a Blue arrow light.

9 – 64V

Flood Beam

Red Arrow Marking

820lm

10W

IP66/67/68 Rated

IP67

Download DatasheetView Related Products

Swipe to Browse

Housing Shape Round
Beam Type Spot (arrow)
Raw Lumen Output 820lm
Effective Lumen Output 30lm
Colour Temperature 620~630 nm
Beam Distance see datasheet
Voltage 9 - 96 VDC
Power Consumption 7.3 W
Operating Temp Range -30°C...+65°C
Housing Material Aluminium
Lens Material Polymethyl methacrylate
Dimensions 92.7 x 96.2 x 117.2 mm
Mounting Style Single bolt
Termination Wires 195 mm
Ingress Protection Rating IP67
EMC EN50498
Shock Resistance 7G
Approvals -

Specifications subject to change without notice.
