C2-3027 Round LED Work Light
The C2-3027 is a round LED work light designed for durability and efficiency. It features an aluminium housing and a polycarbonate lens, with three LEDs providing bright and uniform illumination. Operating within a voltage range of 9-33VDC, it consumes 29W of power and provides 3645 raw lumen output, ensuring reliable lighting with low energy usage. The light is designed to withstand harsh conditions, with an IP68/IP69K rating for protection against dust, water, and chemicals, can operate in temperatures from -30 to +85° C, and it offers excellent shock resistance of up to 10G. Approved under ECE R10, ISO 13766, and CISPR 25 Class 3, it meets international standards for electromagnetic compatibility. The LEDs emit a cool white light, enhancing visibility in low-light conditions. These upright mounted work lights come with two lens types, either clear flood or a diffused wide flood beam and are ideal for use in specialist, agricultural, and construction vehicles. Alternatively the light can be supplied complete with a magnetic base and 12 / 24V automotive power connector. Simple and quick to set up makes it Ideal for emergency situations.
Download DatasheetView Related Products
Swipe to Browse
- Specifications
- Standard Parts
|
Part Number
|
Voltage
|
Power Consumption
|
LED Colour Temperature
|
Raw Lumen Output
|
Effective Lumen Output
|
Beam Type
|
Ingress Protection
|
Shock Resistance
|
EMC
|
Accessories
|
Termination
|
|---|---|---|---|---|---|---|---|---|---|---|---|
| C2-3027 | 9-33 VDC | 29W | 5700K | 3645 Lumen | 2600 Lumen | Flood ~ 80m | IP68 / IP69K | 10G | ECE R10, ISO13766, CISPR25 CLASS3 | N/A | DT04-2P Connector |
| C2-3027W | 9-33 VDC | 29W | 5700K | 3645 Lumen | 2600 Lumen | Wide Flood ~ 66m | IP68 / IP69K | 10G | ECE R10, ISO13766, CISPR25 CLASS3 | N/A | DT04-2P Connector |
| C2-3027A | 9-33 VDC | 29W | 5700K | 3645 Lumen | 2600 Lumen | Flood ~ 80m | IP68 / IP69K | 10G | ECE R10, ISO13766, CISPR25 CLASS3 | Automotive Auxiliary Power Connector | Automotive Auxiliary Power outlet |
| C2-3027AW | 9-33 VDC | 29W | 5700K | 3645 Lumen | 2600 Lumen | Wide Flood ~ 66m | IP68 / IP69K | 10G | ECE R10, ISO13766, CISPR25 CLASS3 | Automotive Auxiliary Power Connector | Automotive Auxiliary Power outlet |
| Housing Shape | Round |
| Beam Pattern | Flood or Wide Flood |
| Raw Lumen Output | 3645 Lm |
| Effective Lumen Output | 2600 Lm |
| Colour Temperature | 5700K |
| Voltage | 9 - 33 VDC |
| Nominal Current at | 2.45A at 12V ~ 1.2A at 24V |
| Power Consumtion | 29W |
| Ingress Protection Rating | IP68 / IP69K |
| Shock Resistance | 10G |
| Operating Temp Range | -30°C...+85°C |
| Housing Material | Aluminium |
| Lens Material | Polycarbonate |
| Dimensions | 84 x 71.5 x 118.5 mm |
| Mounting Style | Single Bolt |
| Termination | Deutsch DT04-2P Connector |
| EMC | ISO13766, CISPR25 CLASS3 |
| Approvals | ECE R10 |
Specifications subject to change without notice.
