Sub-subminiature DF
Economical sub-subminiature switch with coil spring mechanism, offering long overtravel compared to similar models. Ideal for low current applications, extremely reliable and very low initial contact resistance. Certified according to both ENEC and UL standards, so suitable for worldwide use.
- Economical sub-subminiature switch
- Electrical rating 0.1A 48V DC / 0.2A 60V DC UL-certified
- Excellent performance in micro current range
- Operating temperature range -40 to 85°C
- PCB or solder terminal options
- Optional straight or simulated roller actuator
- Mechanical service life min. 1 million operations
- ENEC and UL certified
Download DatasheetView Related Products
Swipe to Browse
- Specifications
- Standard Parts
Part Number
|
Electrical Rating
|
Configuration
|
Operating Force (max.)
|
Terminal Type
|
Actuator Type
|
Actuator Length
|
Datasheet
|
---|---|---|---|---|---|---|---|
DF-03L-0E-Z | 3A 125/250V AC | S.P.D.T. | 80 gf | Solder | Button | - | |
DF-03L-0P-Z | 3A 125/250V AC | S.P.D.T. | 80 gf | PCB long | Button | - | |
DF-03L-1E-Z | 3A 125/250V AC | S.P.D.T. | 30 gf | Solder | Straight lever | 13.00 mm | |
DF-03L-1P-Z | 3A 125/250V AC | S.P.D.T. | 30 gf | PCB long | Straight lever | 13.00 mm | |
DF-03L-3E-Z | 3A 125/250V AC | S.P.D.T. | 35 gf | Solder | Straight lever | 10.00 mm | |
DF-03S-0C-Z | 3A 125/250V AC | S.P.D.T. | 150 gf | PCB RA-left | Button | - | |
DF-03S-0D-Z | 3A 125/250V AC | S.P.D.T. | 150 gf | PCB RA-right | Button | - | |
DF-03S-0E-Z | 3A 125/250V AC | S.P.D.T. | 150 gf | Solder | Button | - | |
DF-03S-0P-Z | 3A 125/250V AC | S.P.D.T. | 150 gf | PCB long | Button | - | |
DF-03S-1A-Z | 3A 125/250V AC | S.P.D.T. | 56 gf | PCB short | Straight lever | 13.00 mm | |
DF-03S-1C-Z | 3A 125/250V AC | S.P.D.T. | 56 gf | PCB RA-left | Straight lever | 13.00 mm | |
DF-03S-1D-Z | 3A 125/250V AC | S.P.D.T. | 56 gf | PCB RA-right | Straight lever | 13.00 mm | |
DF-03S-1P-Z | 3A 125/250V AC | S.P.D.T. | 56 gf | PCB long | Straight lever | 13.00 mm | |
DF-03S-2P-Z | 3A 125/250V AC | S.P.D.T. | 43 gf | PCB long | Sim. roller lever | 15.00 mm | |
DF-03S-3C-Z | 3A 125/250V AC | S.P.D.T. | 57 gf | PCB RA-left | Straight lever | 10.00 mm | |
DF-03S-3D-Z | 3A 125/250V AC | S.P.D.T. | 57 gf | PCB RA-right | Straight lever | 10.00 mm | |
DF-03S-3P-Z | 3A 125/250V AC | S.P.D.T. | 57 gf | PCB long | Straight lever | 10.00 mm | |
DF-03S-4A-Z | 3A 125/250V AC | S.P.D.T. | 69 gf | PCB short | Straight lever | 11.00 mm | |
DF-03S-8P-Z | 3A 125/250V AC | S.P.D.T. | 54 gf | PCB long | Straight lever | 12.00 mm | |
DF-03S-9E-Z | 3A 125/250V AC | S.P.D.T. | 21 gf | Solder | Straight lever | 30.00 mm | |
DF-03S-9P-Z | 3A 125/250V AC | S.P.D.T. | 21 gf | PCB long | Straight lever | 30.00 mm | |
DF-G1S-0E-Z | 0.1A 125/250V AC (gold) | S.P.D.T. | 150 gf | Solder | Button | - | |
DF-G3S-0E-Z | 3A 125/250V AC (gold) | S.P.D.T. | 150 gf | Solder | Button | - | |
DF-P1L-0P-Z | 0.1A 125/250V AC | S.P.D.T. | 80 gf | PCB long | Button | - | |
DF-P1L-1A-Z | 0.1A 125/250V AC | S.P.D.T. | 30 gf | PCB short | Straight lever | 13.00 mm | |
DF-P1L-1P-Z | 0.1A 125/250V AC | S.P.D.T. | 30 gf | PCB long | Straight lever | 13.00 mm | |
DF-P1S-0E-Z | 0.1A 125/250V AC | S.P.D.T. | 150 gf | Solder | Button | - | |
DF-P1S-0P-Z | 0.1A 125/250V AC | S.P.D.T. | 150 gf | PCB long | Button | - | |
DF-P1S-1A-Z | 0.1A 125/250V AC | S.P.D.T. | 56 gf | PCB short | Straight lever | 13.00 mm | |
DF-P1S-1C-Z | 0.1A 125/250V AC | S.P.D.T. | 56 gf | PCB RA-left | Straight lever | 13.00 mm | |
DF-P1S-1E-Z | 0.1A 125/250V AC | S.P.D.T. | 56 gf | Solder | Straight lever | 13.00 mm | |
DF-P1S-1P-Z | 0.1A 125/250V AC | S.P.D.T. | 56 gf | PCB long | Straight lever | 13.00 mm | |
DF-P1S-2A-Z | 0.1A 125/250V AC | S.P.D.T. | 43 gf | PCB short | Sim. roller lever | 15.00 mm | |
DF-P1S-2P-Z | 0.1A 125/250V AC | S.P.D.T. | 43 gf | PCB long | Sim. roller lever | 15.00 mm | |
DF-P1S-4P-Z | 0.1A 125/250V AC | S.P.D.T. | 69 gf | PCB long | Straight lever | 11.00 mm | |
DF-P1S-9E-Z | 0.1A 125/250V AC | S.P.D.T. | 21 gf | Solder | Straight lever | 30.00 mm | |
DF-03S-25P-Z | 3A 125/250V AC | S.P.D.T. | 65 gf | PCB | Roller lever | 10.74 mm |
Characteristic
|
DF Series
|
---|---|
Electrical Rating | 0.1A 125V AC, 1A 125/250V AC, 3A 125V AC |
Circuitry | S.P.D.T., S.P.S.T. - N.O., S.P.S.T. - N.C. |
Ingress Protection | IP40 |
Termination | PCB, Solder |
Agency Approvals | ENEC, UL |
Operating Force | 80gf, 150gf with button actuator, model dependent |
Operating Temperature | -40 to +85 °C |
Electrical Service Life | 0.1A min. 1000000 operations, 10000 operations (other) |
Mechanical Service Life | min. 1000000 operations |
Contact Resistance (initial) | max. 100 Omhm |
Insulation Resistance (initial) | min. 100 mOhm (500V DC for one minute) |
Housing Material | PBT |
Button Material | PBT |
Terminal Material | Brass |
Specifications subject to change without notice.
