Snap-in / eBike / LEV IP6x

Home - Connectivity - Snap-in eBike LEV Connectors - Snap-in / eBike / LEV IP6x

This range of compact IP66/IP67/IP68 connectors is specifically designed for Light Electric Vehicles (LEVs), eBikes and other applications requiring space-saving, environmentally protected connections. The snap-in series provides reliable connectivity for battery systems, motor controls, displays and onboard accessories in demanding mobile applications.

Featuring a quick push-pull locking mechanism that prevents accidental disconnection, these connectors are highly resistant to vibration and environmental exposure. The TPU (thermoplastic polyurethane) housing material offers durable flexibility ideal for outdoor use, withstanding UV exposure and temperature extremes.

Available in 2 to 9-pin configurations with current ratings from 2A to 30A, the connectors support both signal and power applications. Panel mount and inline versions are offered, with pre-wired cable assemblies available to customer specifications.
  • IP66/IP67/IP68 protection
  • 2 to 9-pin configurations
  • Current ratings from 2A to 30A
  • Vibration-resistant push-pull locking
  • TPU housing for outdoor durability
  • Panel mount and inline options
  • ROHS, TUV/VDE and UL compliant
  • Operating temperature: -40°C to +85°C

Snap-In

IP66/67/68 Rated

up to IP67

2 – 9 Pins

up to 30A

60V

Download DatasheetView Related Products

Swipe to Browse

  • Specifications
  • Standard Parts
Part Number
Description
Datasheet
GT1S1401-01060 Snap-in, IP67, 2A (6P), female, M6 panel mount pdf
GT1S1401-02030 Snap-in, IP67, 5A (3P), female, M6 panel mount pdf
GT1S1411-01060 Snap-in, IP67, 2A (6P), male, M6 panel mount pdf
GT1S1411-02030 Snap-in, IP67, 5A (3P), male, M6 panel mount pdf
GT1S1424-01062-02 Snap-in, IP67, 2A (6P), female, M6 cable end, 2000 mm cable pdf
GT1S1424-02032-02 Snap-in, IP67, 5A (3P), female, M6 cable end, 2000 mm cable pdf
GT1S1434-01062-02 Snap-in, IP67, 2A (6P), male, M6 cable end, 2000 mm cable pdf
GT1S1434-02032-02 Snap-in, IP67, 5A (3P), male, M6 cable end, 2000 mm cable pdf
GT1S1401-02020 Snap-in, IP67, 5A (2P), female, M6 panel mount pdf
GT1S1411-02020 Snap-in, IP67, 5A (2P), male, M6 panel mount pdf
GT1S1424-02022-02 Snap-in, IP67, 5A (2P), female, M6 cable end, 2000 mm cable pdf
GT1S1434-02022-02 Snap-in, IP67, 5A (2P), male, M6 cable end, 2000 mm cable pdf
GT1S1401-01050 Snap-in, IP67, 2A (5P), female, M6 panel mount pdf
GT1S1411-01050 Snap-in, IP67, 2A (5P), male, M6 panel mount pdf
GT1S1424-01051-02 Snap-in, IP67, 2A (5P), female, M6 cable end, 2000 mm cable pdf
GT1S1434-01051-02 Snap-in, IP67, 2A (5P), male, M6 cable end, 2000 mm cable pdf
GT1S1434-01051-02(Y) Snap-in, IP67, 2A (5P), male, M6, colour coded yellow, cable end, 2000 mm cable pdf
GT1S1424-01051-02(Y) Snap-in, IP67, 2A (5P), female, M6, colour coded yellow, cable end, 2000 mm cable pdf
GT1S1401-01050(Y) Snap-in, IP67, 2A (5P), female, M6, colour coded yellow, panel mount pdf
GT1S1411-01050(Y) Snap-in, IP67, 2A (5P), male, M6, colour coded yellow, panel mount pdf

Specifications subject to change without notice.
